Model |
Knife Height (mm) |
Knife Width (mm) |
Thickness (mm) |
Angle (°) |
Max Cutting Depth (mm) |
Applications / Materials |
Notes |
|
38.00 |
8.50 |
1.5 |
0–15 |
~8.5 |
Honeycomb, foam, packaging materials |
Oscillating knife, Kimla 40/10 type |
|
|
60.00 |
10.00 |
1.5 |
0–10 |
Not specified |
General cutting (suitable for Atom, MLA) |
Oscillating knife, Kimla 60/25 type |
|
|
Not explicitly stated (60mm approx) |
Not explicitly stated (10mm approx) |
1.5 |
Not specified |
Up to 50 mm |
Honeycomb, cardboard, foam, packaging |
Oscillating knife for Atom cutters |
|
|
130.00 |
10.00 |
1.5 |
87 |
100.00 |
Foam board, packaging materials, synthetic materials |
Flat, oscillating blade, deep cutting |
|
|
Approx. 58.3 |
14.00 |
1.5 |
Not specified |
30.00 |
Foam, packaging, textiles, soft materials |
tungsten carbide, rounded tip variant similar to 40505 |
|
|
Not found detailed |
Not found detailed |
Not found |
Not found |
Not found |
Not available |
Limited public data |
.Blades 01040074F to 01040075F are smaller and suited for thinner materials like honeycomb and packaging with max cutting thickness varying around 8.5mm (74F) to general use in thicker materials (75F).
.01040076F is for thicker materials up to 50 mm including foam and cardboard.
.01040077F is a large, deep-cutting oscillating blade allowing max cutting depth up to 100 mm, with an 87° blade angle for precision on thicker synthetic and foam boards.
.01040504F is a tungsten carbide oscillating blade with a rounded tip variant of 40505 type, used for soft materials up to 30mm thickness, providing durability with a rounded tip to avoid breakage.
.Detailed specs or applications for 01040507F are not publicly available.
All blades are oscillating type, compatible with Atom cutting systems, and often used for foam, packaging, honeycomb, textiles, and synthetic materials cutting. Thickness is generally 1.5 mm for stability and longevity. The cutting depth and angle vary based on the blade design and intended material.
